Model	945-65
Engine Model	YUNNEI 4105 pressure
Rated Power	110KW
Rated Speed	2400r/min
Number of cylinders - inner diameter	4-105
Dimension	700020002850mm
Wheel Base	2720mm
Minimum ground clearance	320mm
The performance parameters
System Pressure	28Mpa
Weight	8500kg
Maximum speed	38km/h
Max Climb Capability	35°
Minimum turning radius	4300mm
Mining parameters
Maximum excavation depth	3000mm
Excavation unloading height	4100mm
Maximum excavation radius	4800mm
Bucket width	60mm
Bucket capacity	0.25m³
Maximum excavation height	5600mm
Maximum Digging Force	36KN
Rotary Angle of excavator	280°
Loading parameters
Maximum unloading height	3600mm
Maximum unloading distance	900mm
Bucket width	20 00mm
Loading capacity	1.2M3
Maximum lift height for loading	4750mm
Maximum rising power	100KN
Shovel action time and	6.8s
Steering system type	Articulated full hydraulic steering
Steering Angle	38°
Tire	16/70-24
Front wheel air pressure	300-350kPa
Rear wheel air pressure	300-350kPa
Service brake	air top oil caliper disc brake
Parking brake	Air brake
Fuel tank/Hydraulic oil tank	70L/140L
Driving Type	4WD
